Mosquito® Hotend Kit with Silicone Boot
Mosquito® Hotend Kit with Silicone Boot
Mosquito® Hotend Kit with Nozzle
Mosquito Heat Sink Top
  • Load image into Gallery viewer, Mosquito® Hotend Kit with Silicone Boot
  • Load image into Gallery viewer, Mosquito® Hotend Kit with Nozzle
  • Load image into Gallery viewer, Mosquito Heat Sink Top

Mosquito® Hotend

68 Reviews
| 41 answered questions
Regular price
Sale price
Unit price
The Mosquito® is a high-performance 3D printer hotend with precise temperature control and exceptional thermal efficiency. The Mosquito’s patented design provides a compact, lightweight solution that prevents clogging and allows for effortless One-Handed Nozzle Changes™.

Looking for 2.85 mm compatibility? Click here.

7 in Stock


Frequently bought with:

Additional Features and Benefits

  • Compatible with RepRap style nozzles (M6 x 1.0 threads with a 7 mm thread length)
  • Compatible with Mosquito Silicone Boots
  • Rigid “roll cage” structure for One-Handed Nozzle Change™
  • Rated to 500°C
  • 100% Made in the USA

Hotend Kit Includes:

  • Mosquito Hotend*
  • GammaMaster® Nozzle - 0.4 mm
  • Mosquito Silicone Boot
  • Boron Nitride Paste - 1 cc
  • Hotend Mounting Hardware
  • Hotend Wrench Set
  • Gourmet Lollipop (Made in the USA)

*Fan, Heater Cartridge, & Temperature Sensor sold separately

Drop element here
Moquito Hotend Printing

Rigid “Roll Cage” Structure

Machined out of aircraft-grade aluminum, the Mosquito Hotend’s heat sink is built like no other on the market. Designed with our patented “roll cage” design, the heat sink connects to the hot block with a rigid tubular structure. This unique feature protects the delicate heat break from crashes and other abuse and allows one-handed nozzle changes.

Bimetallic Heat Break™

Bimetallic Heat Break™

Mosquito’s Bimetallic Heat Break is designed to eliminate heat creep and jamming, improve print resolution and allow for shorter retractions. Crafted with a highly conductive copper alloy and strain-hardened, abrasion-resistant steel, this heat break conducts 85% less heat up the filament path when compared to standard threaded heat breaks.

Super-Conductive Hot Block

Super-Conductive Hot Block

Mosquito’s hardened copper alloy hot block is nickel plated and rated to 500°C, enabling printing of every commercially available filament, from basic PLAs to custom, medical-grade PAEKs. The hot block design isolates the sensor from the heater with a physical air gap, improving the temperature feedback loop.

Mosquito Silicone Boot with Nozzle

Equipped for Excellence

Every Mosquito Hotend comes with three essential accessories that elevate your 3D printing experience. The GammaMaster® Nozzle excels in even the most demanding applications with robust, abrasion-resistant performance and exceptional thermal capabilities. Safeguard your hot block with the Mosquito Silicone Boot, providing essential protection from cold air and filament for optimal performance. Additionally, Boron Nitride Paste, a thermal conduction enhancement, and potting agent, is included to simplify heater and sensor installation.

Technical Specifications

Dimensions 27 x 18 x 41 mm
Mass 37 g
Cooling Air
Filament Diameter 1.75 mm or 2.85 mm
Temperature Rating 500°C
Maximum Flow Rate Capacity 35 mm3/s
Nozzle Compatibility M6 x 1.0 (7 mm thread length)
Maximum Heating Power 50 W (12 or 24 V)
Temperature Sensor Compatibility 15 mm length, ø 3 mm
Number of Temperature Sensors 1
Manufacturing Made in the USA

Hotend Comparisons

The Original Mosquito® Mosquito® Magnum Mosquito Magnum+® Mosquito® Prime™
Max Flow Rate Capacity 35 mm3/s (156 g/hr) 40 mm3/s (179 g/hr) 90 mm3/s (402 g/hr) 116 mm3/s (516 g/hr)
Nozzle Orifice 0.2 – 0.8 mm 0.4 – 1.2 mm 0.4 – 1.8 mm 0.8 – 1.8 mm
Mass* 37 g 41 g 73 g 103 g
Overall Height* 41 mm 41 mm 60 mm 88 mm
Max Power 50 W 50 W 100 W 150 W
Filament Size 1.75 or 2.85 mm 1.75 mm 1.75 or 2.85 mm 1.75 or 2.85 mm

* Air-Cooled Version (1.75 mm); Mass/height includes the heat sink, heat break, & hot block
